High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

Name: High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB
Brand: kampa
Price: 5.00 USD

Buy cheap High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB product

Place of Origin : Zhejiang, China, CN;ZHE

Brand Name : kampa

Model Number : EZ9R36226

Rated Voltage : 240V

BCD Curve : C

products name : High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

Type : RCCB, Residual Current

Pole : 2pole/4pole

rccb Type : AC types/A types

Certificate : CE/CB/ISO/CCC

Rated current : 25A/32A/40A/63A

Breaking capacity : 6kA/10kA

Standard : GB10963/IEC60898

Rated frequency : 50/60 Hz

Rated Frequency : 50/60hz

Poles Number : 2P/4P

Packaging Details : standard export carton

Port : ningbo/shanghai

Supply Ability : 100000 Piece/Pieces per Month

MOQ : 1000 Pieces

Price : $5.00 - $8.00/Pieces

Contact Now

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

1. Introduction of Residual Current circuit breaker

Easy 9 Series Residual Current Circuit Breaker (without over- current protection) is suitable for the line of AC50/60Hz, voltage 240V(2 pole)/ 415V(4 pole), rated current up to 63A. When there is human electricity shock or if the leakage current of the line exceeds the prescribed value it will cut off the power rapidly to protect human safety and prevent the accident from the current leakage. It is applicable to industrial area, commercial area, tall building and civil house.It complies with standard IEC/EN 61008.1 and GB1696.1

Frame class	63A
Rated working voltage	240/415V
Rated frequency	50/60Hz
Rated working current	16, 25, 40, 63A
Rated residual operating current	10mA, 30mA, 100mA, 300mA, 500mA
Rated residual un-operating current	15, 50 , 150 , 250mA
Sensibility	A& AC
Maximum operating time	IΔn t ≤ 0.1s, 5I Δn t ≤ 0.04s
Rated making and breaking capacity	ln≤50A 500A, ln≤63A 630A
Limiting value of un-operating current	6ln
Rated limiting short-circuit current	6000A/10000A
Pole No.	2P, 4P
Mechanical life	20000
Electric life	4000

2. Pictures of Residual Current circuit breaker

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

3. Production Line of Product

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

4. More Product for You to Choose

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

5. Packing of Product

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB

6. Sample Rooms of Product

High quality EZ9R36226 Easy9 2 pole 6ka 25A 30mA RCCB
